flow_dissector: Parse batman-adv unicast headers
Commit Message
The batman-adv unicast packets contain a full layer 2 frame in encapsulated
form. The flow dissector must therefore be able to parse the batman-adv
unicast header to reach the layer 2+3 information to allow RPS to schedule
the flow to different cores.
Signed-off-by: Sven Eckelmann <sven.eckelmann@openmesh.com>
---
I've played around with the RPS+XPS to better distribute traffic to
different cores on modern SoCs. It was observed that the batman-adv unicast
traffic stayed at one core and this limited the overall throughput.
The test was done between a modern PC which was running iperf over
batman-adv. Another PC was also running iperf was just transmitting the
traffic over ethernet. A QCA Dakota (IPQ4018) based device was in the
middle and received the ethernet traffic on one port, encapsulated it as
batman-adv unicast and transferred the resulting packet via ethernet to the
modern PC.
$ iperf -c 192.168.23.2 -t 30 -i 1 -P16
It was observed that only the receive processing was affected. Adding this
relative simple patch allowed me to increase the ethernet throughput from
689 Mbits/sec (with one core doing the interrupt processing and 1 core
completely busy with the other processing) to 910 Mbits/sec (one core doing
the interrupt processing and the other 3 cores were sharing the load). In
theory, the device with the patch could have handled a lot more traffic
than 910 Mbit/sec - at least the RPS cores were not even near 100% load.
This should bring a lot more when testing with good 802.11ac WiFi links
because the wifi stack/driver are usually stressing the CPU a lot more than
normal ethernet drivers.
The change itself is not really invasive but could be a lot cleaner when
the packet header information would be available under include/... . And I
don't know yet whether it would make sense to add a new flow dissector key
with the batman-adv destination address. This is also the reason why I only
post this to the b.a.t.m.a.n@lists.open-mesh.org mailing list.
Anyway, maybe some other people ran into the same problem and want to test
it.
---
net/core/flow_dissector.c | 33 +++++++++++++++++++++++++++++++++
1 file changed, 33 insertions(+)
Comments
On Montag, 27. November 2017 13:33:41 CET Sven Eckelmann wrote:
> The batman-adv unicast packets contain a full layer 2 frame in encapsulated
> form. The flow dissector must therefore be able to parse the batman-adv
> unicast header to reach the layer 2+3 information to allow RPS to schedule
> the flow to different cores.
>
> Signed-off-by: Sven Eckelmann <sven.eckelmann@openmesh.com>
> ---
[...]
Arghh, this should have been an RFC. I will mark it this way in patchwork but
please don't be confused on the mailing list about the subject.
Kind regards,
Sven
@@ -595,6 +595,39 @@ bool __skb_flow_dissect(const struct sk_buff *skb,
break;
}
+ case htons(ETH_P_BATMAN): {
+ /* TODO provide struct in include/uapi/... header */
+ struct batadv_unicast_packet {
+ u8 packet_type;
+ u8 version;
+ u8 ttl;
+ u8 ttvn;
+ u8 dest[ETH_ALEN];
+ };
+
+ struct {
+ struct batadv_unicast_packet batadv_unicast;
+ struct ethhdr eth;
+ } *hdr, _hdr;
+
+ hdr = __skb_header_pointer(skb, nhoff, sizeof(_hdr), data, hlen,
+ &_hdr);
+ if (!hdr)
+ goto out_bad;
+
+ if (hdr->batadv_unicast.version != 15)
+ break;
+
+ if (hdr->batadv_unicast.packet_type != 0x40)
+ break;
+
+ /* TODO set batman-adv dest address as flow key? */
+
+ proto = hdr->eth.h_proto;
+ nhoff += sizeof(*hdr);
+
+ goto again;
+ }
case htons(ETH_P_8021AD):
case htons(ETH_P_8021Q): {
const struct vlan_hdr *vlan;
